Question 1: Designing a Parameterized N-bit Comparator

In the realm of digital design, comparators stand as stalwart guardians, discerning equality or inequality between binary values. Let's embark on a journey to design a parameterized N-bit comparator in VHDL, a task that tests both your ingenuity and command over the language.

Solution:

```vhdl
library IEEE;
use IEEE.STD_LOGIC_1164.ALL;

entity NBit_Comparator is
    generic(
        N : integer := 8  -- Default to 8-bit comparator
    );
    port(
        A, B : in std_logic_vector(N-1 downto 0);
        EQ   : out std_logic;
        LT   : out std_logic;
        GT   : out std_logic
    );
end entity NBit_Comparator;

architecture Behavioral of NBit_Comparator is
begin
    EQ <= '1' when A = B else '0';
    LT <= '1' when A < B else '0';
    GT <= '1' when A > B else '0';
end architecture Behavioral;
```

Question 2: Implementing a Finite State Machine (FSM) for Traffic Light Control

In the realm of embedded systems, efficiency and safety converge at the intersection of traffic light control. Designing a Finite State Machine (FSM) to orchestrate this dance of vehicles demands meticulous planning and flawless execution. Let's explore a scenario and craft a VHDL solution that ensures smooth traffic flow.

Solution:

```vhdl
library IEEE;
use IEEE.STD_LOGIC_1164.ALL;

entity Traffic_Light_FSM is
    port(
        clk       : in std_logic;
        reset     : in std_logic;
        green_out : out std_logic;
        yellow_out: out std_logic;
        red_out   : out std_logic
    );
end entity Traffic_Light_FSM;

architecture Behavioral of Traffic_Light_FSM is
    type state_type is (Green, Yellow, Red);
    signal current_state, next_state: state_type;

begin
    process(clk, reset)
    begin
        if reset = '1' then
            current_state <= Red;  -- Initial state
        elsif rising_edge(clk) then
            current_state <= next_state;
        end if;
    end process;

    process(current_state)
    begin
        case current_state is
            when Green =>
                green_out  <= '1';
                yellow_out <= '0';
                red_out    <= '0';
                next_state <= Yellow after 10 ns; -- Transition to Yellow after 10 ns
            when Yellow =>
                green_out  <= '0';
                yellow_out <= '1';
                red_out    <= '0';
                next_state <= Red after 5 ns; -- Transition to Red after 5 ns
            when Red =>
                green_out  <= '0';
                yellow_out <= '0';
                red_out    <= '1';
                next_state <= Green after 15 ns; -- Transition to Green after 15 ns
        end case;
    end process;
end architecture Behavioral;
```
